Shocker Gooseneck Air Hitch & Coupler for PJ Trailer

Select Option:

Clear

Product Information:

List Price: $1,129.99Sale Price: $1,099.99Free Ground Shipping*

Reviews
Rated 4.86 out of 5 based on 7 customer ratings
SKU: SH-900WF-4-PJ-Trailer

-

Product Description

  • Smoother Safer Towing: Improves your ride, reduces wear & tear on pickup & trailer.
  • Easy Install: Completely replaces your factory gooseneck stem & coupler with Gooseneck Surge Air System & Coupler. Installs in Minutes.
  • Absorbs Road Shock: Helps eliminate tugs, jerks & bumps felt when towing on rough roads or concrete highways.
  • Built in Airbag: This hitch directs the tow resistance through an airbag, producing a smooth ride.
  • 30,000 lbs Tow & 7,000 lbs tongue weight: Available with 30k dual latching Shift Lock gooseneck coupler.
  • Air Ride Technology: Protects your truck, gooseneck trailer and the contents with a smoother, safer tow. Heavy loads, just add air. The cure for choppy, bouncy, buckled, rough & busted up roads. No more booms, bangs and jerks when towing with your gooseneck.
  • Custom Fit: Available for  4″ Round & 3-15/16″ Square or 4″ Square PJ Gooseneck Flatdeck & Dump Trailers.
  • Fits 2-5/16″ gooseneck hitch balls: & has 3 height adjustment holes. (Standard coupler extends 3″ forward from your factory coupler or choose 9″ extension for short bed pickups)
  • Includes complete Shocker Gooseneck Surge® air hitch with built in airbag, replacement inner tube stem & 30,000 lb Shift Lock™ gooseneck coupler for 2-5/16″ ball.
  • Have a different trailer brand? Click this link to Find Your Gooseneck Surge Air Hitches by Trailer Mfg

Shocker Hitch Guarantee

Free Ground Shipping* | Shocker Guarantee | Free Returns

Air ride upgrade for PJ gooseneck trailers. Upgrade your gooseneck PJ trailer with an gooseneck surge® air hitch. The integrated airbag Shocker Gooseneck Surge® air hitch & 30,000 lb coupler system is the ultimate in gooseneck trailer towing for your PJ trailer. This shock absorbing cushion hitch is the only air ride hitch to exclusively work in a forward and back motion, which is often times this is the biggest jerk you feel when towing gooseneck trailers. Works great on PJ flatbed, tilt, deckover, dump, roll off dump trailers.  The built in airbag absorbs the road shock and filters the bumps through the airbag creating a smoother, safer towing experience for you, your pickup, your trailer & the contents. Featuring the patent pending exclusive 30K Shift Lock™ Couplers for 2-5/16″ hitch balls  Upgrade your gooseneck trailer with the smooth towing solution. Whether you are an occasionally tow or are doing hotshot trucking, this gooseneck hitch adds instant air ride to your hauling. This is the preferred gooseneck hitch for hotshot haulers who tow all over the country. Available for Gooseneck trailers with either round tube, square and crank handle style stems. The shock absorbing hitch for a gooseneck trailer is made for smooth and safe towing. Works great on gooseneck style end dumps, flatbed, race haulers, livestock, toy haulers, tilt, horse trailers and more. Completely replaces your PJ factory stem & coupler with the Gooseneck Surge Hitch system & 30,000 lbs gooseneck air coupler. Installs in minutes. Made by Shocker Hitch® USA in Arthur, ND.

Fits PJ gooseneck trailers with either a 4″ round stem or 100mm (3-15/16″) square and a 4″ square stem.  Replacement inner tube stem has 3 adjustment holes and the coupler extends 3″ forward from factory location or you can also order it with a 9″ offset coupler for short bed pickup trucks.

Adjustable for Tow Weight: The air bag sits behind your gooseneck hitch and out of the way. You will find the advantage of the Air Shocker is your ability to adjust air pressure for best ride and load control. View our Shocker PSI Air Pressure tuning guide.

Air Ride Hitch Technology: Shocker Air is designed with a built-in air bag for a smoother towing experience. Just add air depending on the weight of your trailer and its’ contents. An air bag is simply the best cushion device on the planet.

Simple Pivot Design: Uses a rocker arm pivot design which produces a front and back motion, much different than other cushion hitches on the market. Our design eliminates the need for parallel linkages, shock absorbers, torsion arms and other over engineered gadgets.

Shock Dampening & Absorbing Action: Shocker air hitch effectively absorbs the jerking, tugging and damaging forces experienced with a typical hard connection when towing trailers. There is no reason to beat yourself or your equipment up with a hard connection.

Improves Safety: By giving you improved control of your tow vehicle and trailer. The Gooseneck surge air hitch system allows for better control of your pickup and the trailer it is towing.

Shift Lock™ Coupler: 30,000 lbs rated, patent pending gooseneck coupler. The only gooseneck coupler that captures ball on both sides. At a glance, you can see if the coupler is locked on the ball. Easy to use handle to hook up and disconnect the coupler from the ball. Plus it extends your factory hitch 3″ forward.

Saves Fuel: By using a gooseneck Surge Hitch, you may save as much as one mile per gallon. When we developed the Surge Hitch our intention was to give a smoother ride, period.

Adds Life To Your Vehicle & Gooseneck: By reducing wear and tear on driveline and frame! Treat yourself, your equipment, and your passengers to a much smoother ride. You’ll never go back to the ‘old days’ of continual bumps, jerks, and vibrations. Join the list of satisfied customers that are using Shocker hitches. Order one today and get ready for your ultimate smooth towing experience the next time out.

Saves Money: By reducing trailer breakage on both the trailer and the trailer contents! The Shocker hitch absorbs the damaging forces experienced with a typical hard connection. This greatly reduces the chances of breaking welds and doing other long term damage to your equipment as well as the valuable cargo you have inside the truck and trailer.

Provides Comfort: With a smoother ride! Travel a lot on concrete highways? No more jarring every time you cross a section divider. Your Shocker air hitch absorbs the thumps, bumps and jerks you feel when towing your gooseneck trailer.

California Residents: Prop 65 Warning

Video

Shocker Gooseneck Surge Air Hitch & Coupler Videos

Install a Gooseneck Surge in Minutes

How The Gooseneck Surge Air Hitch Works Video

Gooseneck Surge Hitch for Stem Selection Video

Install

Shocker Gooseneck Surge Air Hitch & Coupler Installation

When used properly these Gooseneck surge air hitch will make noticeable improvements in your gooseneck trailer towing quality. Giving both truck and trailer a smoother ride with less trailer fatigue and breakage.

Install a Gooseneck Surge in Minutes

How to Air Up Gooseneck Surge Air Coupler?

Gooseneck Surge Air Pressure:

  • This is a LOW-PRESSURE hitch, that works by tow resistance.
  • Set air pressure at approx. 5 psi, then test drive.
  • Increase pressure in 5 psi increments until optimum results are found.
  • Typical air pressure range is 5 – 15 psi.
Note: When towing heavy trailers or trailers with high wind resistance it may be necessary to increase air pressure in the Shocker. Maximum Pressure: Do not exceed 100 psi in the air bag, as it may damage the air bag.

Gooseneck Surge Stem Selection Guide Video

Download Gooseneck Surge Installation Manuals

Maximum weights for Shocker Surge: Towing capacity = 24,000 lbs Tongue = 6,000 lbs | Tow Capacity is 30,000 lbs for Wallace Forge Coupler Safety Notice: The Shocker Hitch is a heavy-duty unit, however, it is imperative that any weight capacity ratings are not exceeded on the ball that is mounted on your tow vehicle, or the Shocker Hitch. Use only a 2 5/16″ dia. Ball. V-19 rated. Do not exceed G.V.W.R. of ball being used.
Gooseneck Surge Diagram
Gooseneck Surge Diagram

Installation

  1. Take a vertical measurement from the bottom of the ball coupler tube to the bottom of the trailer frame sleeve. This dimension will be used to set the Shocker Gooseneck Surge Trailer Hitch
  2. Remove pins or loosen locking bolts on the trailer frame sleeve, and remove the existing coupler tube.
  3. Slide Gooseneck Surge Shocker Hitch insert tube inside the trailer frame sleeve with the air bag toward the rear of trailer.
  4. Hold or support Shocker at vertical measurement noted in Step #1. This should duplicate the previous ride height of the trailer. Shockerhitch must be properly aligned, (parallel with trailer), to maximize its benefits. Note: If your trailer coupler tube is equipped with a pin or pins, the correct pin location must be marked in the Shockerhitch insert tube and have a qualified machine shop drill / machine the pin holes.
  5. Torque locking bolts to your trailer manufacturers’ recommended specifications. A spacer kit is available for some applications.
  6. Lubricate: Oil the coupler shaft, grease coupling ball socket, and grease the hitch ball to REDUCE WEAR AND IMPROVE SHOCKER ACTION. Main pivot grease zerk should be greased periodically for maximum bushing life. ( Simply, you cannot over-grease it! )
  7. Hook up the trailer by simply lowering the coupler onto the ball. (Handle will snap open & shut automatically). To release trailer: Pull handle up and hold while raising trailer.
Flatbed Recessed Gooseneck Ball Fitment Guide
Flatbed Recessed Gooseneck Ball Fitment Guide

We’re here to help. Contact Us

Installation Issues

We want you to have the best possible towing experience with your product and proper installation is important. If you need help, we are here for you. Just give us a call at 701-707-2666 or use our contact us form. You can also look up the item’s product page on our website and view the installation tab. Most products on our website have a set-up guide and installation video.

FAQ

Answers to Frequently Asked Questions on the Gooseneck Surge

How do I know the Gooseneck surge with fit my gooseneck trailer? There are two things you need to know. What kind of stem your gooseneck trailer has and what kind of ball your pickup has. You can also find the hitch you need by using our Gooseneck Trailer MFG guide.

What is the Gooseneck surge tow rating?  30,000 lbs towing capacity with Shift Lock coupler for 2-5/16″ ball  / 7,000 lbs tongue weight & 40,000 lbs towing capacity with 40K goose air with Shift Lock coupler for 3″ ball. With a 30k Shift Lock coupler its 30,000 lbs towing capacity & 7,000 lbs tongue weight.

How long will the airbag last? Our airbags are an industrial bag and will last for years and years. They are similar to truck airbags but have been beefed up internally for our towing applications.

Is there a way to lock the Gooseneck coupler? Yes, we do carry a gooseneck coupler lock specially made for our surge hitch as well as a stem set bolt lock. You can check those out here: https://shockerhitch-vip.md-staging.com/product/sl-gooseneck-coupler-set-bolt-locks/

Can you really install the Gooseneck Surge in a couple of minutes? Yes check out the install video.

How much air do I put in the gooseneck surge air hitch?  See air pressure video in install tab.

What do your mean when you say straight or angled / slotted pin holes?  We are wondering if your gooseneck stem has holes that are straight across OR if it is slightly angled 10-30 degrees, where the stem hitch pin is off set or at an angle. Below is a picture of an angled stem, which we would use a stem with slotted holes to fit this angled pin. See our gooseneck stem selection guide.

Will it work with my flat bed pickup with recessed in a flatbed pocket? Yes, see install tab and fitment guide for recessed ball.

If I Order a gooseneck surge air hitch & coupler, what all comes in the box? Includes a complete replacement gooseneck stem, surge air hitch system & coupler along with clear-cut installation instructions. Literally you can install this in 2 to 5 minutes.

How long will it hold air?
This is a sealed system that will hold air for weeks or months. If you haul the same trailer with the same load weight, it should be good for quite some time.

How often do I grease it? The grease does not just lube the pivot; it also keeps water and dirt out. You cannot over grease it, once every few months should do it.

How does the air ride work? The air shocker is like a teeter totter. One end is an air bag, a pivot in the middle, and a ball at the other end. This gives a “pillow” effect at the ball end.

How much does an Shocker gooseneck surge weigh? The Gooseneck Surge Air Hitch & Coupler weighs 93 to 100 lbs depending on the model.

Warranty

This product is back the Shocker Hitch Manufacturer Warranty and the Shocker Hitch Guarantee.

Shocker Hitch Guarantee

Questions and answers of the customers

    I have a PJ trailer with 4” Square but my tube has an adjustable crank on top to lower and raise it. Will this still work with mine
  1. 0 votes
    Q I have a PJ trailer with 4” Square but my tube has an adjustable crank on top to lower and raise ...... Read more
    A You would want to order 4SQ-TC-SL (4" Square with top crank)
  2. what is the difference between 30k coupler & 30k coupler 9”forward
  3. 0 votes
    Q what is the difference between 30k coupler & 30k coupler 9”forward
    A The 9" forward will move the hitch forward so it helps with really short beds that have an issue with the turning radius while towing a gooseneck. If you do not have that issue, you would want the standard 30K coupler.
  4. What kind do I need for my pj trailer? I hold about 25k but I see it says something about square or round
  5. 0 votes
    Q What kind do I need for my pj trailer? I hold about 25k but I see it says something about square ...... Read more
    A PJ Gooseneck trailers can either have a round or square stem. You would need to look at your trailer and identify the stem shape, size and pin hole style.

Send me a notification for each new answer.

7 reviews for Shocker Gooseneck Air Hitch & Coupler for PJ Trailer

Add a review

Your email address will not be published. Required fields are marked *

Customer Reviews

  1. I drive some of the worst highways in the country towing a 40 ft. Hauling oilfield equipment and this is a game changer.

    – Jeff Dugan
  2. I couldn’t believe the difference in the ride with the shocker hitch installed. I hated pulling my 24 foot flatbed, before. The trailer jerked and pounded my truck, constantly. With the new hitch, I could barely feel the trailer was there. Great product, good people to deal with, well worth the money.

    – William Stark
  3. After hearing about the shocker I thought it was just another sale pitch, so I figured I’ve wasted money before on all kind of things so maybe just maybe I might get this one right. And “Bingo” this was money well spent. Thank you shocker for not wasting my money….

    – Mark Smith
  4. At this time all I have done with my new shocker hitch is test my 32′ goose-neck trailer with no load on it other than the trailer itself. I set the air bag at 15 lbs , driving with just the trailer there is a noticeably smoother ride. Before the shocker hitch this particular trailer , empty ,would jerk me around to the point where I dreaded using it. Looking forward to testing it out with a full load , when I do , I’ll get back with complete review.

    – David Henry
  5. Being a hot shot trucker, this gooseneck air hitch really makings towing big loads easier. Smooths out the truck and trailer.

    – Dave’s Hauling Service
  6. A great addition to my PJ trailer. An awesome product to take the jerk out of Your pickup and it feels like You don’t have a 32 foot trailer loaded behind You.
    I recommend it for anyone who has a trailer and hauls heavy loads.

    – Larry Clements
  7. Being a hotshot trucker, this is one of the best upgrade I have added to the operation. Definitely would recommend it to anyone that tows much.

    – Davie Wilson

Weight / Dimensions

Weight 92 lbs
Dimensions 30 × 24 × 12 in
Select Gooseneck Inner Stem Size & Pin Type

Round 4" Angled Pin, Square 3-15/16" StraightPin, Square 4" Straight Pin

Select ShiftLock Gooseneck Coupler

30K Coupler 9"Offset, 30K SL Coupler
